Technical dimensions: Measured with handlebars in vertical position (dimensions in mounting position may vary greatly)

a 850 Width
b 60 Height at the end of the outer bend
c 100 Depth to rear
d -10 Height at end of grip
e 170 Measured at intersection of tube outer edges

Dimensions in mounting position: (Dimensions may vary depending on handlebars and mounting).

0 Height
70 Depth to rear (Pullback)

Other dimensions:

230 Maximum handle length
155 Maximum clamp width
120 / 60 Width of knurling (outside / inside)
