Description





Technical dimensions: Measured with handlebars in vertical position (dimensions in mounting position may vary greatly)

a 660 Width
b 105 Height at the end of the outer bend
c 105 Depth to rear
d 110 Height at end of grip
e 200 Measured at intersection of tube outer edges

Dimensions in mounting position: (Dimensions may vary depending on handlebars and mounting).

100 Height
95 Depth to rear (Pullback)

Other dimensions:

175 Maximum handle length
119 Maximum clamp width
120 / 60 Width of knurling (outside / inside)
